Fiat e-Doblo dimensions

The Fiat e-Doblo Cargo is a compact city van that is built on the shared Stellantis small van platform, but the E-Doblo is a van with plenty of space.

Keep reading to find out the Fiat e-Doblo's length, height and width as well as details of its loadspace and the Fiat e-Doblo's load volume.

The sizes and dimensions of this van also apply to the Fiat Doblo Cargo with a diesel engine.

Some of the most common questions about the Fiat e-Doblo and Fiat Doblo dimensions are:

Is a Fiat Doblo bigger than a Berlingo?

Once upon a time the Fiat Doblo was built on a different chassis to the Citroen Berlingo. That Doblo was significantly larger than the Berlingo. However, all new Fiat Doblo and Fiat e-Doblo vans are now exactly the same as the Berlingo. They're all part of the Stellantis family of vans and share the same size with the Peugeot Partner and Vauxhall Combo.

What size is a Fiat Doblo van?

The Fiat Doblo and Fiat e-Doblo are classed as a small, compact or city vans. It measures 4.4m in length, 1.7m wide and is 1.8m high. A long wheelbase model Doblo is 4.75m long.

Is Fiat Doblo a small van?

Yes. The Fiat Doblo is a small panel van from the Stellantis family of vans that include the Citroen Berlingo, Peugeot Partner and Vauxhall Combo. The Toyota Proace City is also built on the same platform. All of these vans are the same size but available in two difference body lengths and with electric powertrains.

Fiat E-Doblo Length

There are two different sizes to the Fiat e-Doblo range. The short wheelbase van - which is called an L1 - is the smaller of the two vans. The e-Doblo L1 short wheelbase van measures 4403mm in length, bumper to bumper.

The long wheelbase van, which is the L2 model, is the bigger version. The e-Doblo L2 long wheelbase van has a total length of 4753mm.

A side profile view of the Fiat E-Doblo Cargo with the dimensions added showing the height, length, wheelbase and front and rear overhangs
E-Doblò Van Short WheelbaseE-Doblò Van Long Wheelbase Doblò Crew
Wheelbase (mm)27852975
External Length4403mm4753mm4753mm
External height (m)  from 1.80 to 1.86  from 1.80 to 1.86  from 1.80 to 1.86
Load volume (m³) without/with Magic Cargo  from 3.3 to 3.8  from 3.9 to 4.4  from 3.5 to 4
Load compartment:
maximum length (m)
without/with long items opening

from 1.8 to 3.1  from 2.2 to 3.4  from 2.2 to 3.4
Load compartment:
maximum height
(m)
1270  1270  1270
Load compartment:
width of rear door
(m)
124112411241
Load compartment: PPT (kg)800kg  800kg  800kg
Seats2/32/35
Dimensions of a Fiat e-Doblo on a diagram with the measurements for the long-wheelbase model van
Updated: January 1, 2024
Written by: thevanreviewer
