The Iveco Daily 50C moves into heavy-duty territory with higher axle capacities and twin rear wheels, but it also rewrites the measurements and sizes. In this guide we'll look at the overall Iveco Daily 50C dimensions, looking at the two wheelbases sizes and both H2 and H3 roof heights.
The Iveco Daily 50C is the 5-tonne version of the regular Iveco Daily van. It enables more payload, but also increases the size options for this big van. However, it's still not the biggest van on sale in the Iveco range.
If you're interested in the smaller 3.5-tonne van, then read our guide to the Iveco Daily 35S dimensions, or you can look at the supersized Iveco Daily 70C dimensions, instead.
Lets take a look at the Iveco Daily 50C sizes.
The Daily 50C moves into twin rear wheel territory and offers higher axle capacities and heavier payload ratings.
Load volume for the ranges from 12m³ to 19.6m³, making it one of the largest panel vans in its class.
Available with H2 and H3 roofs, it stretches to 7,674mm in extended body sizes and provides up to 19.6m³ of load space with a maximum loadspace length of up to 5.1m.
The Iveco Daily 50C is available in two wheelbase lengths of 3.5m and 4.1m. This gives the Daily 50C an overall length of between 6.1m and 7.6m.
| Model | Wheelbase | Overall length |
|---|---|---|
| 50C | 3520mm | 6109mm |
| 50C | 4100mm | 7274mm |
| 50C | 4100mm (extended) | 7674mm |
The Iveco Daily 50C has the same overall width as the rest of the Iveco Daily family with an external width of just over 2m.
| Iveco Daily | Overall width (cab) |
|---|---|
| 50C Van | 2052mm |
There are two roof heights available on the Iveco Daily 50C, with the smaller H2 measuring 2.75m high and the bigger H3 van coming in at just under 3m.
| Iveco Daily | Roof | Overall height |
|---|---|---|
| 50C | H2 | 2748–2752mm |
| 50C | H3 | 2944–2945mm |
There's a huge jump in the available sizes of the Daily 50C's maximum internal length, because the rear overhangs of the van create such an enormous loadspace.
The smallest vans have a total length of 3.5m, while the largest can more maximum lengths of just over 5.1m in the rear loadspace. That's as much overall length as some vans are in total length!
| Iveco Daily | Internal length |
|---|---|
| 50C (12m³) | 3540mm |
| 50C (16m³) | 4680mm |
| 50C (18m³) | 4680mm |
| 50C (19.6m³) | 5125mm |
There are two differing wheelbase options available on the Iveco Daily 50C with a 3.5m wheelbase or a 4.1m wheelbase model.
| Iveco Daily | Wheelbase options |
|---|---|
| 50C | 3520mm, 4100mm |
The Iveco Daily comes in four different sizes with overall cubic capacity ranging from 12 cubic metres up to 19.6 metres cubed.
| Iveco Daily | Volume |
|---|---|
| 3520WB H2 | 12m³ |
| 4100WB H2 | 16m³ |
| 4100WB H3 | 18m³ |
| 4100WB Extended H3 | 19.6m³ |
19.6 cubic metres.
Yes — H3 models approach 3 metres in height.
