So need to find out the Vauxhall Movano dimensions and this is the right place to do that. In this guide we'll tell you all about the size of the Vauxhalll Movano van from its length, width and height down to the internal dimensions, cubic capacity or load volume. If you're looking for the size of the Opel Movano dimensions, don't worry this is also the same van.
The Movano is one of the many large vans from Stellantis and is known for its generous size with a wide range of lengths and roof heights to choose from.
As a result the Vauxhall Movano is one of best vans for carrying large items and has generous external and internal dimensions. Previously based on the same platform as the Renault Master, the Movano is now built on the same chassis as the Peugeot Boxer, Citroen Relay and Fiat Ducato making it one of the most in-demand chassis for use as a motorhome.
But it doesn't stop there as a camper or panvel van because the Movano is used by a wide range of converters which is why you'll find it as a fridge van, dropside, tipper and even as a Luton van. The Vauxhall badge makes buyers think they're buying British, but this is one of the Sevel-made vans, which is made in Italy.
The Movano is produced in several wheelbase lengths with medium, large and even an extra large version. That means there's a Vauxhall Movano size for all occasions.
This dimensions guide will look at the overall Vauxhall Movano length, width and the movano height. There'll be a breakdown of the Movano dimensions in metres and millimetres of each individual wheel base.
We'll start with the external size and then tell you the Vauxhall Movano internal dimensions for the loadspace. Finally we'll end with an overview of the Vauxhall Movano load volume.
Although this guide is about the Vauxhall Movano dimensions, there's also an article on the Vauxhall Movano van weight and a guide for the Vauxhall Movano towing capacity as well.
The Vauxhall Movano is currently available in three lengths. Vauxhall calls these L2, L3 and L4. Previously they also produced an L1 version, but we'll skip over that because it wasn't very popular. Length is linked to wheelbase - the wheelbase being the distance between the front and rear axles - and the Movano actually has two wheelbase lengths but three body lengths. There's a seperate section on wheelbases after the generic guide to the dimensions but after that we'll refer to the sizes as both their Length and Wheelbase as an interchangeable thing. That's why we'll headline each section with the wheelbase but also the length.
The Vauxhall Movano is available in lengths of 5413mm, 5998mm and 6363mm. These are the lengths for the Vauxhall Movano L2 (standard wheelbase), L3 (long wheelbase) and L4 - which used the same long wheelbase but will be henceforth referred to as the extra-long-wheelbase.
The Vauxhall Movano width is the same for all models with a standard size of 2050mm excluding the mirrors. This is the total width of the body panels on the van.
The width of the Vauxhall Movano including mirrors is 2690mm.
The height of the Vauxhall Movano is a lot more straight forward than its length, despite there being three van heights. The height of the Vauxhall Movano van is reffered to as H1, H2 and H3.
H1 vans are the short stubby looking ones, whereas an H2 Movano van is the one you are most likely to find. The H3 is the extra-high model and adds a considerable amount to the storage height.
Here's a list of the individual heights for the Movano van.
As you can see the overall dimensions of the Vauxhall Movano van are numerous. In the following sections we will break down the sizes available by individual model. There's also tables to illustrate the sizes and a couple of pictures along the way.
Overall, the Vauxhall Movano has dimensions from 5.4m to 6.4m in length, 2.05m width, and a height from 2.25m to 2.76m.
As mentioned before there are just two wheel base sizes for the Vauxhall Movano but the largest van uses the bigger wheelbase to create an even longer van. This is because the largest van has a much larger rear overhang.
The wheelbase lengths available on the Vauxhall Movano are 3450mm and 4035mm. The 3450mm wheelbase is used for the L2 size vans. The 4035mm wheelbase is used for the L3 and L4 models of the Movano.
Medium wheelbase is a bit of a misleading term, because it is the smallest van available on the Movano, but since the smallest version is no longer available, the L2 size will have to do. So, while still not the middle, it remains as the medium-size van.
The Vauxhall Movano MWB length is 5413mm or 5.4m and is available in two different roof heights.
The Movano van can be had in a 2.25m height version or a 2.522m.
5413mm L x 2050mm W x 2254mm H
3120mm L x 1870mm W x 1662mm H
5413mm L x 2050mm W x 2522mm H
3120mm L x 1870mm W x 1932mm H
The Vauxhall Movano LWD dimensions add around 500mm to the overall length and the maximum load length of the van, when compared to the standard van.
The Vauxhall Movano LWB length is 5998mm or 5.99m and is available in two different roof heights.
The Movano van can be had in a 2,522m height or a 2,760mm model.
5998mm L x 2050mm W x 2522mm H
3705mm L x 1870mm W x 1932mm H
5998mm L x 2050mm W x 2760mm H
3705mm L x 1870mm W x 2172mm H
The Vauxhall Movano extra-long wheel base model gets all of its extra length from the rear overhang of the van. The L4 Movano has the same wheelbase length as the L3, so the distance between the front axle and the rear axle are the same. The big difference is in the additional length of the rear portion of the van. There's an extra 365mm of length in the rear overhang. Same wheelbase, but extra length.
6363mm L x 2050mm W x 2522mm H
4070mm L x 1870mm W x 1932mm H
6363mm L x 2050mm W x 2760mm H
4070mm L x 1870mm W x 2172mm H
The Vauxhall Movano has a load volume ranging from 10m3 to 17m3 depending on the size of the van.
The smallest model, the L2H1 van has a load volume of just 10m3 which is just slightly larger than the biggest medium van. Where the real volume differences begin is with the additional height that can be offered by these vans. The L2H2 Movano with the MWB has a capacity of 11.5m3.
Next is the range is the L3H2 with a 13m3 capacity and the L4H2 with a 15m3 loadspace.
An extra high roof makes the van look a bit ungainly but adds a significant amount of space with the L3H3 Boxer large enough to take up to 15m3 load volume. The largest Movano van for load capacity is the L4H3 with a massive 17m3 capacity.
This is currently the largest storage volume of any large van, but the Movano isn't alone in being able to claim that. The Movano's siblings, the Citroen Relay, Fiat Ducato and the Toyota Proace Max all sharing the same dimensions.
There are additional guides to the Citroen Relay dimensions, Fiat Ducato dimensions and Peugeot Boxer dimensions available in the van dimensions section.
The Vauxhall Movano has a load volume ranging from 10m3 to 17m3 depending on the size of the van.
