It’s the latest model to be based on the Stellantis medium van platform, so you’re probably looking for the Iveco eJolly dimensions because it’s piqued your interest.
Maybe you’re looking to find out the eJolly height, or its length?
In this article we’ll cover everything there is to know about the Iveco eJolly dimensions. We’ll look at what are the internal dimensions of a eJolly van and what cargo length the eJolly can carry.
In this guide we’ll look at everything you’ll need to know about the size of the Iveco eJolly and its dimensions.
The medium electric van comes in a number of different sizes, with a range of different body lengths available for the eJolly. So, if you want to know all there is to know about the Iveco eJolly dimensions you’ll find it all below, including the Iveco eJolly height, eJolly length and the Iveco eJolly width.
This dimensions guide is for the current and first generation of the Iveco eJolly electric van but it also applies to many of the Stellantis made siblings. That means these dimensions are the same for the Opel Vivaro, Citroen Dispatch, Peugeot Expert, Fiat Scudo and the Toyota Proace dimensions.
There are separate guides for each of those models on the van dimensions page, as well as for the electric van alternatives like the Fiat E-Scudo and Peugeot E-Expert.
The eJolly is based on one of Britain's best-selling vans, the Vauxhall Vivaro, so you’re getting a much loved and very suitable van. However it’s really important to know the dimensions of the eJolly before you take the plunge.
The eJolly is available in two lengths, with a standard L1 or SWB eJolly measuring 5m and an L2 or long wheelbase LWB eJolly measuring 5.3m.
There's only one Iveco eJolly height option which means there’s no high roof model, just a standard height eJolly van of up to 1.94m.
The eJolly width is 2.2m excluding the mirrors.
That's the Iveco eJolly size in a nutshell, but keep reading for the exact details of the eJolly van dimensions.
The Iveco eJolly is a new name but there’s still a lot of questions about its dimensions. These’re are the most commonly asked eJolly dimension questions:
The Iveco eJolly SWB dimensions are: 4981mm (L) x 2204mm (w) x 1904mm (h)
The Iveco eJolly LWB dimensions are: 5331mm (L) x 2204mm (w) x 1935mm (h)
If you want to compare the size of the Iveco eJolly with either of the Ford vans you can use our Ford Transit Custom dimensions guide or the Ford Transit dimensions article.
| Exterior Dimensions (mm) | Iveco eJolly | Iveco eJolly XL |
|---|---|---|
| Length | 4981 | 5331 |
| Width (with mirrors) | 2204 | 2204 |
| Height | 1904 | 1935 |
| Wheelbase | 3275 | 3275 |
The height of the Iveco eJolly is the same for all models because there’s no high roof eJolly van.
That means that the only change in the height depends on the length of the van and even then it’s really really small.
The short wheel base eJolly has a height of 1904mm, but the long wheelbase eJolly is wver so slightly higher and has a 1934mm height.
We’ve already road that there are two different lengths for the eJolly. The eJolly comes in an L1 standard short wheelbase eJolly van or as a longer L2 long-wheelbase eJolly model.
Overall lengths for the two vans range from 4981mm to 5331mm.
All eJolly vans share the same overall width which means that the Iveco eJolly width is 2204mm for all variants.
Because there are two body lengths, but only one height, there’s not much change between the smallest and largest capacity eJolly vans in the line-up.
Iveco eJolly vans can carry up to 6.6m3. They also have a maximum load length of 2.86m and a load height of 1397mm.
There’s 1636mm of space at the widest point in the eJolly rear, which reduces down to 1258mm between the wheel arches.
| Loadspace Dimensions (mm) | Iveco eJolly | Iveco eJolly XL |
|---|---|---|
| Max length at load floor | 2512 | 2862 |
| Max load length mid-height | 2185 | 2535 |
| Max length with load-through bulkhead | 3674 | 4024 |
| Max length at load floor – Doublecab | 2017 | 2365 |
| Max load length mid-height – Doublecab | 1352 | 1700 |
| Maximum width | 1636 | 1636 |
| Width between wheel arches | 1258 | 1258 |
| Maximum height | 1397 | 1397 |
The load space of the Iveco eJolly is up to 5.8 cubic metres for the SWB eJolly, and up to 6.6 cubic metres for the LWB eJolly.
The length, height and width of the eJolly van are all pretty standard but the internal size of the eJolly gets a bit more complicated.
It has a folding bulkhead hatch which allows longer lengths to go under the passenger seat. A neat little trick which helps keep long times of pipe or trim safe and secure inside the van rather than on the roof.
As there’s a choice of two van lengths, there are two different measurements for the overall maximum length of the eJolly load space which is up to 3.67m in the standard version, and 4.02m in the long version of the eJolly.
The Iveco eJolly's dimensions are dramatically improved with the hatch, making it as possible to carry similar lengths to a large van, but in a medium van.
The large van adds 341mm to the overall length of the eJolly, with most of that increase carried over into the size of the eJolly load area which increases by 320mm for the long wheelbase XL van.
The Iveco eJolly SWB has a regular load length of 2512mm while the Iveco eJolly long wheel base van has a load length of 3852mm.
Both the SWB and LWB models have a folding bulkhead load hatch which bumps the maximum length to 3670mm for the standard and 4020mm for the long version.
Even the smallest Iveco eJolly is quite large with a minimum overall load volume of 5.3m3 which is increased to 5.8m3 when you include the bulkhead hatch.
The eJolly XL long-wheelbase has a slightly larger overall load volume of 6.1m3 that increases to 6.6m33 with the load through hatch taken into account.
| Load Volume (m3) | Iveco eJolly | Iveco eJolly XL |
|---|---|---|
| Panel van | 5.3 | 6.1 |
| Panel van with load-through bulkhead | 5.8 | 6.6 |
| Doublecab | 3.2 | 4 |
If you can’t get things through the doors then a van is pretty much useless, so the load access is as important as the internal dimensions and the overall size of the eJolly.
The eJolly comes with a single side-load door as standard, which has an aperture of 935mm. This is the size of the opening across the width of the door. It’s wide enough to side-load a Euro pallet.
Other important measurements of the eJolly are the rear doors, which open to 90 degrees as standard to give you an opening of 1282mm.
| Loadspace access (mm) | Iveco eJolly | Iveco eJolly XL |
|---|---|---|
| Side door aperture height | 1241 | 1241 |
| Side door aperture width | 935 | 935 |
| Rear door aperture height | 1220 | 1220 |
| Rear door aperture width | 1282 | 1282 |
| Loading height – Maximum | 613 | 633 |
| Loading height – Minimum | 544 | 600 |
The Iveco eJolly short wheel base (SWB) is another name for the standard length van. The length of the Iveco eJolly SWB is 4.98m long. It has an overall load length of 2.51m which is extended to 3.6m with the load through bulkhead.
The Iveco eJolly long wheel base (LWB) is the name for the longest length van, and the eJolly van with the biggest overall dimensions. The length of the Iveco eJolly LWB is 5.33m long.
It has an overall load length of 2.86m. This can then be increased to which is increases to just over 4m when using the load through bulkhead.
The Iveco eJolly has an overall maximum height of 1935mm. There is no high roof version, but the short-wheelbase van is 30mm lower in its roof height. The internal roof height of the eJolly is 1397m.
