This comprehensive guide to the Iveco eSuperJolly dimensions provides all the essential details about one of the market's most spacious vans.
It might be a new name in the van market, but the Iveco eSuperJolly is built on a van that is renowned for its generous dimensions and versatility. That means that the Iveco eSuperJolly stands out as one of the most adaptable vans for both its external and internal measurements.
This versatility makes it a popular choice for conversions and explains its widespread use across industries such as refrigerated transport, low loaders, Luton vans and motorhomes.
Available in a range of wheelbase lengths including medium, large and extra-large, the Iveco eSuperJolly dimensions will suit a wide variety of needs.
This guide covers everything there is to know about the size of the large electric van, with the Iveco eSuperJolly length, width and height, detailing each wheelbase’s specific dimensions and providing an overview of the eSuperJolly load volume and other important internal measurements.
For information on the Iveco eSuperJolly payload capacity and towing capabilities, separate dedicated guides are available.
Let's delve into the eSuperJolly van’s sizes and explore the specifications on offer for this Stellantis-made large van.
The overall dimensions of the Iveco eSuperJolly vary considerably.
The Iveco eSuperJolly ranges from 5.4m to 6.4m in length, with a width of 2.05m and heights spanning from 2.25m to 2.76m.
The current Iveco eSuperJolly range features three length options, designated as L2, L3 and L4.
The eSuperJolly length correlates to the wheelbase length, which is the distance between the front and rear axles. Interestingly, the eSuperJolly features two wheelbase lengths but spans three body lengths. This is because the same wheelbase is used for the largest van with an extended rear overhang.
The Iveco eSuperJolly is available in lengths of 5413mm, 5998mm and 6363mm. These correspond to the L2 (standard wheelbase), L3 (long wheelbase) and L4 (extra-long wheelbase) models, with the L4 eSuperJolly sharing the L3 long wheelbase but extended with a larger rear overhang.
Across all models, the Iveco eSuperJolly has a width of 2050mm, excluding the wing mirrors. This measurement is for the total width of the van's body panels, edge to edge.
Including mirrors, the eSuperJolly width increases to 2690mm.
The overall height of the Iveco eSuperJolly is more straightforward compared to its length, although there are three roof height options.
The Iveco eSuperJolly heights comes in three categories, as H1, H2 and H3.
H1 is for the shortest version, H2 is the most commonly found model and H3 represents the extra-high roof version.
Here are the specific height measurements for the eSuperJolly:
Iveco eSuperJolly H1 height: 2245mm or 2.25m
Iveco eSuperJolly H2 height: 2522mm or 2.5m
Iveco eSuperJolly H3 height: 2760mm or 2.76m
The Iveco eSuperJolly offers two wheelbase options, with the largest variant utilising the longer wheelbase to achieve additional length through an extended rear overhang.
The wheelbase lengths are 3450mm and 4035mm. The 3450mm wheelbase applies to L2 models, while the 4035mm wheelbase supports both the L3 and L4 configurations.
Despite being termed "medium wheelbase," it is effectively the smallest available eSuperJolly. As there’s no L1 option, the L2 serves as the medium-size option but also the entry point into the range.
The Iveco eSuperJolly MWB features a length of 5413mm or 5.4m and offers two roof height choices either 2250mm or 2522mm.
The long wheelbase (LWB) version increases the overall and maximum load length by approximately 500mm compared to the standard model.
The Iveco eSuperJolly LWB measures 5998mm or 5.99m in length, with two available roof heights of 2522mm and 2760mm.
Iveco eSuperJolly L3H2 exterior dimensions:
5998mm L x 2050mm W x 2522mm H
Iveco eSuperJolly L3H2 interior dimensions:
3705mm L x 1870mm W x 1932mm
Iveco eSuperJolly L3H3 exterior dimensions:
5998mm L x 2050mm W x 2760mm
Iveco eSuperJolly L3H3 interior dimensions:
3705mm L x 1870mm W x 2172mm H
The extra-long wheelbase (ELWB) Iveco eSuperJolly derives its added length from an extended rear overhang, as it shares the same wheelbase as the L3. The key difference lies in the addition of a 365mm rear extension, to create much more extra cargo space in the rear of the van.
Iveco eSuperJolly L4H2 exterior dimensions:
6363mm L x 2050mm W x 2522mm H
Iveco eSuperJolly L4H2 interior dimensions:
4070mm L x 1870mm W x 1932mm H
Iveco eSuperJolly L4H3 exterior dimensions:
6363mm L x 2050mm W x 2760mm H
Iveco eSuperJolly L4H3 interior dimensions:
4070mm L x 1870mm W x 2172mm H
The load volume of the Iveco eSuperJolly ranges from 10m³ to 17m³, depending on the van’s size.
The compact L2H1 variant offers a load volume of 10m³, slightly larger than the biggest medium van in the market. The L2H2 model with the MWB provides 11.5m³ of capacity.
Progressing up the range, the L3H2 accommodates 13m³, while the L4H2 boasts a 15m³ load area.
The extra-high roof versions, though pretty clunky in their appearance, significantly boost capacity. The L3H3 holds up to 15m³, and the largest option, the L4H3, offers a substantial 17m³.
With the largest storage volume among large vans, the eSuperJolly shares its dimensions with its counterparts, including the Peugeot Boxer, Citroen Relay, Vauxhall Movano, Fiat Ducato and Toyota Proace Max.
For more detailed comparisons, guides on the dimensions of the Citroen Relay, Fiat Ducato dimensions, Peugeot Boxer dimensions, Toyota Proace Max dimensions and Vauxhall Movano dimensions are available in the van dimensions section along with many many more.
This is a great question, because the eSuperJolly and the Daily essentially operate in the same space. The eSuperJolly is definitely not bigger, but it is about the same size.
The two models don't share any components, so they're very different, but they are both available in multiple body sizes as a 3.5-tonne van. The Iveco Daily and the Iveco eDaily are, however, both available at much higher GVWs.
